Product Information

Material Carbon Steel
Type Compression (Single Ferrule)
Usage For Hydraulic Application
Pressure 100 Bar Series LL Very Light
  160 Bar 315 Bar Series L Light
  315 Bar 630 Bar Series S Heavy
Temperature –40 °C 120 °C
Size 4 mm  OD 42 mm  OD

Product Standards

Material Carbon Steel
EN1A L : BS 970-1
Design Dimensions
DIN 2353
ISO 8434-1

BRAND WESS
ORIGIN INDIA

Product Gallery

References

Material

  • BS 970-1:1996
    Specification for wrought steels for mechanical and allied engineering purposes. General inspection and testing procedures and specific requirements for carbon, carbon manganese, alloy and stainless steels
    Website

Design

  • DIN 2353
    Non-soldering compression fittings with cutting ring - Complete fittings and survey
    Website

  • ISO 8434-1:2007
    Metallic tube connections for fluid power and general use -- Part 1: 24 degree cone connectors
    Website
