Product Information

Material Brass
Type Compression (Single Ferrule)
Usage For Hydraulic Application
Pressure 100 Bar Series LL Very Light
  160 Bar 315 Bar Series L Light
  315 Bar 630 Bar Series S Heavy
Temperature –60 °C 175 °C
Size 6 mm  OD 57 mm  OD

Product Standards

Material Brass
CA377 / UNS C37700 : ASTM B124
Design Dimensions
DIN 2353
ISO 8434-1

BRAND WESS
ORIGIN INDIA

Product Gallery

References

Material

  • ASTM B124 / B124M - 16
    Standard Specification for Copper and Copper Alloy Forging Rod, Bar, and Shapes
    Website

Design

  • DIN 2353
    Non-soldering compression fittings with cutting ring - Complete fittings and survey
    Website

  • ISO 8434-1:2007
    Metallic tube connections for fluid power and general use -- Part 1: 24 degree cone connectors
    Website
